OHLINS Shock - 13.5" - STX Performance - SOFTAIL Fat Bob / Heritage Classic '18-'24
_small.png?v=24178208168894044801788563850)
Öhlins STX 36 Performance rear shock in the 13.5" length for taller 2018-and-later Harley-Davidson Softails — Fat Bob and Heritage Classic. Monotube, nitrogen charged, adjustable preload, and built to be serviced rather than replaced.
Features
- STX 36 Performance monotube design
- High-pressure nitrogen gas charged
- Adjustable spring preload
- Hard-anodized, precision CNC-machined components
- Low-friction shaft and sealhead design
- Fully serviceable, re-valvable and re-sprung
- Sold individually — one shock per bike
Fitment
| Model | Years |
|---|---|
| FXFB Fat Bob 107 | 2018-2019 |
| FXFBS Fat Bob 114 | 2018-2023 |
| FLHC Heritage Classic 107 | 2018-2021 |
| FLHCS Heritage Classic 114 | 2018-2024 |
| FXBBS Street Bob 114 | 2022 |
Want rebound and compression adjusters too? The STX Pro (HD 517) is the fully adjustable 13.5" shock.
Specifications
| Öhlins P/N | HD 515 |
| Model | STX 36 Performance |
| Extended length | 13.445" |
| Stroke length | 2.244" |
| Spring included | Öhlins 21102-41 (B) — 115 N/mm |
| Maximum rider weight | 250 lb (range 170-250 lb) |
| Preload adjuster | Standard |
| Material | Aluminum |
| Mounting position | Rear |
| Sold as | Each |
